Led Wall Panels Display
13.1' x 6.6' FT
Create a more immersive and professional meeting environment with a high-resolution LED wall engineered specifically for conference halls and corporate presentation spaces. The LED Market P2.5mm 13.1′ x 6.6′ screen is designed for venues where clarity, reliability, and seamless integration matter.
specs
Pixel Pitch: 2.5
Pixel Density: 200 x 200 per panel
High Refresh Rate: 7680Hz
LED Configuration: 3-in-1 SMD2020 LED
Size: 19.7″ x 19.7″ x 3″ / 500 x 500 x 75mm
Weight: 14.5Kg
Full Front Service: Magnetic Modules
Module Quantity: 8 per panel 250 x 250mm
Conference halls require sharp visuals from short distances. With a 2.5mm pixel pitch and an optimal viewing distance of approximately 6 feet, this LED wall delivers detailed imagery without visible pixelation (even for front-row attendees).
Distance 6ft
2.5MM
Indoor conference environments demand controlled brightness and stable playback. With 1600 NITS, this LED wall provides clear, comfortable visibility without overpowering the room’s lighting design. Enginnered by the NovaStar MRV208-1 receiving card at 7680 Hz, the system ensures smooth visuals, stable synchronization, and flicker-free performance.
Conference centers and corporate facilities need technology that’s dependable and easy to maintain. This LED screen features full front service access with magnetic modules, allowing maintenance teams to replace modules quickly without dismantling the structure. The modular architecture reduces service time and keeps disruptions to a minimum.
Ready for Any Conference Hall Installation Setup
Ready for Any Conference Hall Installation Setup
Ideal for permanent integration into conference rooms, auditoriums, and boardrooms. This method creates a clean, flush aesthetic while maximizing floor space.
Perfect for flexible conference environments, temporary installations, or event centers that require adaptable staging solutions.
A professional option for larger halls and event venues where truss systems are used. This setup allows precise positioning and integrates seamlessly with lighting and AV production equipment.
With USA-based inventory and nationwide shipping, your project benefits from faster deployment timelines. LED Market provides 24/7 U.S.-based support for setup, troubleshooting, and ongoing operation.
Engineered for continuous operation, this system offers a 100,000-hour operating life and includes a comprehensive 5-year warranty covering all parts. It’s built as permanent presentation infrastructure; not a temporary AV solution.
All components are stocked in the USA, allowing fast access to replacement parts and minimizing downtime. With support for Composite, S-Video, Component, VGA, DVI, HDMI, and HD-SDI inputs, integration into existing AV ecosystems is straightforward and efficient.
Turn-Key Packages
Turn-Key
Packages
5-Year Warranty
5-Year
Warranty
Technical Support
Technical
Support
Package Includes
LED video tiles
for rigging (*)
included
Link Cables
link cables
Edison Cables
cable
In today’s business environment, presentation quality directly reflects brand credibility. Whether hosting leadership summits, corporate town halls, product launches, or hybrid meetings, the LED Market P2.5mm LED Screen delivers the clarity, reliability, and professional presence that modern conference halls demand.
Upgrade your venue with a display solution designed to communicate with confidence, and make every presentation count.
Technical Specifications
- Full Front Service / Magnetic Modules
- Turn-key solution
- Easy installation
- Ground support compatible (sold separately)
- Download full specifications here
- Technical support available
- 5-year warranty included for all parts
- USA based
- In stock
- Operation Power: 100~240V 50-60Hz
- Max. Power Consumption: 150W/per panel
- Ave. Power Consumption: 120W/per panel
- Connections Power/Data: Locking power In/Out; Data EtherCon In/Out
- Control Mode: NovaStar Synchronous System with Control via DVI
- Frame Update Frequency: 60Hz
- Scan Mode: 1/16
- Refresh Rate: 7680Hz
- Support Input: Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI
- Brightness Correction: Pixel, Module, Cabinet
- Pixel Pitch: 2.5mm
- NovaStar MRV208-1 receiving card
- LED Configuration: 3-in-1 SMD2020 LED
- Pixel Density: 200 x 200 per panel
- Size: 19.7″ x 19.7″ x 3″ / 500 x 500 x 75mm
- Module Quantity: 8 per panel 250 x 250mm
- Weight: 32lbs. / 14.5Kg
- Brightness: 1600 NITS
- View Angle: Horizontal 140°/Vertical 140°
- Distance: 6ft
- Brightness Adjustment: 0~100% 100 Levels
- (32) Mirackle® NovaStar P2.5mm Indoor LED video tiles
- (1) MI-1000 Video Processor with HDMI, DVI and VGA Inputs
- (8) Hanging bars for rigging (*)
- (3) Cat6 25ft cable
- (32) Data Cat6 link cables
- (32) Locking Power Link Cables
- (3) Locking Power to Edison Cables
- Spare parts included
- Operating Life: 100,000 Hours
- Protection Level: IP65 (Front and Back)
LED Video Wall Screen 13.1′ x 6.6′ P2.5mm Indoor Turn-key
With a video processor with HDMI, DVI and VGA inputs, this P2.5mm indoor LED video wall contains 32 panels to form an 8 by 4 mosaic screen. Its 2: 1 landscape aspect ratio makes this screen a medium size – ideal for transmitting unique and original content, which amazes and captivates viewers with its resolution and image quality. The P2.5mm is an extremely versatile panel, with many opportunities for deployment. Its versatility is matched by its affordability, making it a great choice for churches, houses of worship or even virtual production studios. Download full specifications here Key Features:- Full Front Service / Magnetic Modules
- Turn-key solution
- Easy installation
- Ground support compatible (sold separately)
- Technical support available
- 5-year warranty included for all parts
- USA based
- In stock
- (32) Mirackle® NovaStar P2.5mm Indoor LED video tiles
- (1) MI-1000 Video Processor with HDMI, DVI and VGA Inputs
- (4) Hanging bars for rigging (*)
- (2) Cat6 25ft cable
- (32) Data Cat6 link cables
- (32) Locking Power Link Cables
- (2) Locking Power to Edison Cables
- Spare parts included
Specs:
- Pixel Pitch: 2.5mm
- Novastar A8 receiving card
- LED Configuration: 3-in-1 SMD2121 LED
- Pixel Density: 200 x 200 per panel
- Size: 19.7″ x 19.7″ x 3″ / 500 x 500 x 75mm
- Module Quantity: 8 per panel 250 x 250mm
- Weight: 32lbs. / 14.5Kg
- Brightness: 1600 NITS
- View Angle: Horizontal 140°/Vertical 140°
- Distance: 5ft (1.5 m)
- Brightness Adjustment: 0~100% 100 Levels
- Operation Power: 100~240V 50-60Hz
- Max. Power Consumption: 150W/per panel
- Ave. Power Consumption: 120W/per panel
- Connections Power/Data: Locking power In/Out; Data EtherCon In/Out
- Control Mode: NovaStar Synchronous System with Control via DVI
- Frame Update Frequency: 60Hz
- Scan Mode: 1/16
- Refresh Rate: 7680Hz
- Support Input: Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI
- Brightness Correction: Pixel, Module, Cabinet
- Operating Life: 100,000 Hours
- Protection Level: IP65 (Front and Back)
